PC043TN25-B9.3

您现在的位置:首页 > 液晶屏产品 > 组装液晶屏 >
  • PC043TN25-B9.3
  • PC043TN25-B9.3
  • 型号:PC043TN25-B9.3
  • 品牌:
  • 尺寸:组装液晶屏
  • 分辨率:480×272
  • 亮度:450 cd/m2
  • 视角:70/70/50/70
  • 接口:RGB
  • 对比度:500:1 (Typ.) (透射)
  • 工作温度:-20~+70℃
  • 是否量产:量产中
  • 技术参数
  • 产品描述
  • Item

    Specification

    LCD Model

    PC043TN25-B9.3

    LCD size

    4.3 inch(Diagonal)

    Driver element

    a-Si TFT active matrix

    Resolution

    480 × 3 (RGB) × 272

    Luminance

    450 cd/m2

    Display mode

    Normally White, Transmissive

    Dot pitch

    0.066(W) × 0.198(H) mm

    Active area

    95.04(W) × 53.856(H) mm

    Module size

    105.5(W) × 67.2(H) ×3.0(D) mm

    Viewing angle

    70/70/50/70

    Contrast ratio

    5001

    Surface treatment

    Anti-Glare

    Color arrangement

    RGB-stripe

    Interface

    Digital

    Backlight Power consumption

    TBD W(Typ.)

    Panel Power consumption

    TBD W (Typ.)

    Weight

    TBD (Typ.)

    Operation temperature

    -20 ~70

    Storage temperature

    -30 ~80
